Triple 13.3″ E-Paper Bus Stop Display System

BSS1330

Triple 13.3″ E-Paper Bus Stop Display System

MyGica BSS1330 is a triple-screen 13.3″ E-Paper bus stop solution featuring three independent Carta displays with 1600×1200 resolution. It enables real-time multi-screen information delivery such as arrivals, alerts, and route updates. Built on reflective E-Paper technology, it supports wireless connectivity and flexible deployment for modern transit infrastructure.

Triple display independent for multi-information delivery
Paper-like display with ultra-low power consumption
Seamless integration with ITS platforms, GPS, and GIS systems
Flexible installation: ground, wall, or pole mounting
DC / solar + battery hybrid power support
Wide operating temperature range: -15°C to 60°C

Display Screen	3 × 13.3″ E Ink, 1600 × 1200 resolution, 16 grayscale
CPU	Quad-core ARM Cortex-A55
OS	Android 10
Memory & Storage	4GB RAM, 16GB eMMC (expandable to 128GB)
Connectivity	Wi-Fi 2.4G/5G, Bluetooth 5.0
Battery & Range	DC 12V/2A & 5V/3A, optional solar + battery pack
Operating Temperature	-15°C to 60°C
Installation	Ground-mounted, wall-mounted, or pole-mounted options
